Collets

Are you aware that we sell collets?

We have hundreds available from stock - in bar types, round, square & hexagon.

multiborecollets
Crawford Multibore 'B' Type All Sizes
Crawford Multibore 'C' Type All Sizes
Crawford Multibore 'D' Type All Sizes
Crawford Multibore 'E' Type All Sizes
Spring Type 2046 (E Sprint / MS-26) All Sizes
Spring Type B & S Type 21All Sizes

These are used collets that have beeen thoroughly checked & are in excellent condition.

Prices are subject to VAT at the current rate. Delivery is extra.

Microsprint 26
Microsprint 32
Sprint E
Microsprint 50
Sprint S
Collet Range Collet Code No. Collet Code No.
Inch Metric Round A/F Hex A/F Sq Round A/F Hex A/F Sq
1/16 - 3/16 1.58 - 4.76 B.1B.68B.86 D.1
1/8 - 1/4 3.17 - 6.35 B.2B.69B.87 D.2D.69D.87
1/4 - 3/8 6.35 - 9.52 B.3B.70B.88 D.3D.70D.88
3/8 - 1/2 9.52 - 12.70 B.4B.71B.89 D.4D.71D.89
1/2 - 5/8 12.70 - 15.87 B.5B.72B.90 D.5D.72D.90
5/8 - 3/4 15.87 - 19.05 B.6B.73B.91 D.6D.73D.91
3/4 - 7/8 19.05 - 22.22 B.7B.74 D.7D.74D.92
7/8 - 1 22.22 - 25.39 B.8B.75 D.8D.75D.93
1 - 11/8 25.39 - 28.57 B.9 D.9D.76D.94
11/8 - 11/4 28.57 - 31.75 D.10D.77D.95
11/4 - 13/8 31.75 - 34.92 D.11D.78D.96
13/8 - 11/2 34.92 - 38.10 D.12D.79D.97
11/2 - 15/8 38.10 - 41.27 D.13D.80D.98
15/8 - 13/4 41.27 - 44.45 D.14D.81
13/4 - 17/8 44.45 - 47.62 D.15D.82
17/8 - 2 47.62 - 50.80 D.16D.83
2 - 21/8 50.80 - 53.97 D.17

Please ring 01384-633968 to discuss your collet requirements.
